QUASER - Machining Center - Vertical Stock-No. 02790
MORE machine IMAGES
VIDEO
Offer details
Stock-No.
02790
Type of machine
Machining Center - Vertical
Make
QUASER
Type
MV-204 CPL/12
Year of manufacture
2011
Type of control
CNC
Control name
Fanuc 18i-MB
Technical details
x-travel
1.500 mm
y-travel
700 mm
z-travel
610 mm
Control
Fanuc 18i-MB
turning speeds
12.000 U/min
table dimensions (lengthxwidth)
1.700 x 700 mm
workpiece weight
2.000 kg
tool change unit
48
tool adaptor
ISO 40
max. torque
191 Nm
engine output
30 kW
weight of the machine ca.
9,5 t
dimensions of the machine ca.
4.475 x 2.952 x 3.030 m
additional information
- - new spindle December 2017
- - chip conveyor
- - internal cooling through spindle center 20 bar
- - coolant system with 600 l volume, with efficient filtering and strong pump
- - mechanical tool measuring / break control Renishaw TS-27R with measuring
- cycles
-
